For sheet-fed flatbed steel-rule work, the complete sheet layout turns the initial dimensions into a production-based label cutting die price. Five inputs make a label cutting die quote comparable: usable die size, number of positions, total cutting line, steel rule choice and required delivery date.
Die size and number of positions set the first cost boundary
Label dimensions start the calculation; sheet size and position layout complete it. The same label can be imposed differently on a small sheet and a larger press sheet. As the dieboard grows, more board area is machined. As the number of positions rises, the same shape is bent and fitted more times.
Order quantity tells the printer how many sheets may run, while sheet size and layout describe the work needed to manufacture the die. A useful brief separates finished label size, sheet size, usable cutting area and requested layout.
Contour length and shape complexity change the workload
A rectangular barcode label and a custom label with several concave turns carry different workloads, even when their perimeter is similar. Tight turns, short rule sections and closely spaced lines demand more bending and joint control. The quotation reflects that work.
A single closed production contour gives the die maker a clear source. Cleaning duplicate paths, open ends and overlapping lines before laser cutting helps the quotation follow the actual drawing work.
Rule height, point thickness and coating are separate choices
A barcode cutting rule is specified by its trade name and dimensions. The verified specification used by İkram Lazer is 12 mm rule height and 1.5 point thickness. Titanium edge coating is recorded as a separate option and evaluated against the material and repeat-work plan.
Kiss cutting, through cutting and different facestocks each receive their own rule decision. Paper, direct thermal or filmic facestock and the liner construction belong in the quotation brief. Selecting the right rule before production supports a more predictable total cost.
Delivery pressure and revision planning affect total cost
An urgent delivery can require production sequencing to change, so standard and priority work are planned separately. State the required dispatch time when the file is sent.
A size or corner change made after production adds further work. Matching one approved master contour to the press sheet and feed direction before manufacturing reduces revisions. When comparing quotes, review the drawing check and revision scope included in each price.
Send one consistent package for comparable quotations
Send every candidate supplier the same measured contour, sheet size, machine area, facestock, liner, cut type and deadline. That makes the numbers comparable and exposes any missing assumption.
- Finished label dimensions and closed vector contour
- Sheet size, feed direction and requested positions
- Paper, thermal, PP or PET facestock and liner
- Kiss cut or through cut requirement
- Rule height, point thickness and coating request
- Required dispatch time and repeat-order plan
Information package for a label die quote
Send dimensions, material and sheet plan together to receive a quotation based on the same production assumptions.
- Measured vector contour
- Actual sheet and machine area
- Positions and feed direction
- Facestock, adhesive and liner
- Cut type and rule request
- Deadline and repeat-order plan
